330w 15R beam spot wash 3in1 moving head

MOQ ：1 piece

Lead Time ：15 Days

Inquiry Start Order

Seller Support : Trade Authenticity Guaranteed & Accepting

Payment : L/C,T/T,Western Union,Money Order

Departure Port : Huangpu,Guangzhou

Product details

Supply Ability

Supply Ability：1000 piecesWarranty(Year)：1 Year

Packaging & Delivery

Length：80 cmWidth：60 cm
Height：90 cm
Packaging：2 piece

Product Specifications

Material：Iron

Product Description

PLATINUM BEAM 17R 350W Wash Spot Beam 3 In 1 Moving Head Stage Light

1, Product Features

● Pan 540° or 630 (User selectable) / Tilt 270°

● 3 operation mode: DMX controlled, stand alone, or sound activated

● 3 DMX Modes:

23 Channel – Standard

21 Channel – Basic

34 Channel - Extended

● 8 user colors plus white (including CTO Filter)

● User selectable color change modes (mode 1: full colors, mode 2: split-

colors)

● Two Gobos Wheels:

Wheel 1: Rotating gobo wheel with 8 gobos plus open, all gobos can

be easily replaceable and gobo indexing

Wheel 2: Static/Fixed gobo wheel with 14 gobos plus open

● Strobe effect: 0~13 (13 HZ) flashes per second or random strobe

● Prism and prism rotation, with 16 prism macros

● Frost Filter for Soft and Hard Edge Spot

● Electronic Power Supply (AC 100V-240V~, 50Hz/60Hz)

● Control board with full color LCD graphic display and foil touch keyboard

● RDMX (Remote DMX addressing from any DMX console)(optional)

● Auto test for all functions

● Automatic Pan/Tilt Correction

● Glass Dichroic Reflector for Even Lamp Output

● Anti-Reflective Coated Lenses

● USITT DMX-512 Complaint (3-pin and 5-pin DMX Connections)

● Electronic Focus via DMX

● 7 User Assignable Program Presets - Internal Program: Edit and save

programs to the incorporated EEPROM. Maximum of 64 scenes.

2, Technical Specific

Power supply
Power Requirements	AC 100V-240V~, / 50Hz/60Hz
Fuse Protection	7A/250V, GMA (5x20mm fine-wire fuse)
Power Consumption	520 Watts
Lamp
Type	Platinum 17R
Lamp Wattage	350W
Life time	2200 Hrs
Color temperature	8000K
CRI	75
Optical system	Lenses hardened and tempered, anti-reflex coated
Colors	6 dichroic filter, UV Filter, CTO Filter, plus white, half-color compatible
Gobos
Gobo-wheel 1	8 interchangeable rotating gobos plus "open"
Gobo-wheel 2	14 fixed gobos plus "open"
Prism	Rotating 3-facet prism, rotating and variable in speed
Shutter / Strobe / Dimmer
Strobe effect with variable speed
Continuously mechanical dimmer 0 - 100%
Focus
Motor driven focus from far to near
DMX Channels
23 (16bit – default) or 21 (8bit – user selectable) or 34 (16bit – user selectable)
Drive
Standard DMX-512, 3 pole XLR; [+] = Pin 3 [-] = Pin 2 [Ground] = Pin 1 or 5 pole XLR; n/a = Pin 5, n/a = Pin 4, [+] = Pin 3, [-] = Pin 2, [Ground] = Pin 1 Starting DMX [001].
Pan / Tilt
Pan - movement	630° in max. 16 bit resolution
Tilt - movement	270° in max. 16 bit resolution
Weights and Measures
Width of the base	13” / 33.5cm (Including Handles)
Length of the base	14” / 35.9cm (Without Handles)
Width of Head	16.9” / 43.0cm
Height (head vertical)	19.4” /49.4cm
Weight (net)	23 Kgs / 50.6 Lbs
Operating Noise Levels (Base level 46.8dB)
Mode: Auto	1m = 55.9 dB
Mode: High	1m = 56.2 dB
Mode: Auto	1m = 51.6 db (Lamp off)
Ambient Operating Temperature	-25℃ ~ 45℃
All specifications are subject to change at any time without notice.
